دیتاشیت ADP1761ACPZ-1.0-R7

ADP1761 Datasheet

مشخصات دیتاشیت

نام دیتاشیت ADP1761 Datasheet
حجم فایل 793.547 کیلوبایت
نوع فایل pdf
تعداد صفحات 18

دانلود دیتاشیت ADP1761 Datasheet

ADP1761 Datasheet Datasheet

مشخصات

  • RoHS: true
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: Analog Devices ADP1761ACPZ-1.0-R7
  • Output Current: 1A
  • Output Voltage: 1V
  • Dropout Voltage: 0.053V@(1A)
  • Output Polarity: positive
  • Number of Outputs: 1
  • Maximum Input Voltage: 1.98V
  • Operating Temperature: -40°C~+125°C@(Tj)
  • Quiescent Current (Ground Current): 8mA
  • Package: LFCSP-16
  • Manufacturer: Analog Devices
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Output Configuration: Positive
  • Output Type: Fixed
  • Number of Regulators: 1
  • Voltage - Input (Max): 1.98V
  • Voltage - Output (Min/Fixed): 1V
  • Voltage - Output (Max): -
  • Voltage Dropout (Max): 0.053V @ 1A
  • Current - Output: 1A
  • Current - Quiescent (Iq): 8mA
  • Current - Supply (Max): 11mA
  • PSRR: 67dB ~ 35dB (10kHz ~ 1MHz)
  • Control Features: Enable, Power Good, Soft Start
  • Protection Features: Current Limit, Thermal Overload
  • Mounting Type: Surface Mount
  • Package / Case: 16-WFQFN Exposed Pad
  • Supplier Device Package: 16-LFCSP-WQ (3x3)
  • Base Part Number: ADP1761
  • detail: Linear Voltage Regulator IC 1 Output 1A 16-LFCSP-WQ (3x3)
