دیتاشیت ADM2491EBRWZ-REEL7
مشخصات دیتاشیت
| نام دیتاشیت | ADM2491E |
|---|---|
| حجم فایل | 427.263 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 16 |
دانلود دیتاشیت ADM2491E |
ADM2491E Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Communication Interface Chip/UART/485/232/Digital Isolators
- Data Rate: 16Mbps
- Datasheet: Analog Devices ADM2491EBRWZ-REEL7
- Applications: RS422;RS485
- Supply Voltage: 3.3V;5V
- Forward Channel: 2
- Reverse channel: 1
- Number of Channels: 3
- Isolation Technology: Magnetic isolation
- Operating Temperature: -40°C~+85°C
- Voltage Isolation or Not: Without voltage isolation
- Package: SOP-16-300mil
- Manufacturer: Analog Devices
- Series: iCoupler®
- Packaging: Cut Tape (CT)
- Part Status: Active
- Technology: Magnetic Coupling
- Type: RS422, RS485
- Isolated Power: No
- Inputs - Side 1/Side 2: 2/1
- Channel Type: Unidirectional
- Voltage - Isolation: 5000Vrms
- Common Mode Transient Immunity (Min): 25kV/µs
- Propagation Delay tpLH / tpHL (Max): 60ns, 60ns
- Pulse Width Distortion (Max): -
- Rise / Fall Time (Typ): 20ns, 20ns (Max)
- Voltage - Supply: 3.3V, 5V
- Mounting Type: Surface Mount
- Package / Case: 16-SOIC (0.295", 7.50mm Width)
- Supplier Device Package: 16-SOIC
- Base Part Number: ADM2491
- detail: RS422, RS485 Digital Isolator 5000Vrms 3 Channel 16Mbps 25kV/µs CMTI 16-SOIC (0.295", 7.50mm Width)
