دیتاشیت TPS61005DGSRG4
مشخصات دیتاشیت
| نام دیتاشیت |
TPS61005DGSRG4
|
| حجم فایل |
116.352
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
27
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Converters
-
Function:
boost converterType
-
Topology:
Boost
-
Datasheet:
Texas Instruments TPS61005DGSRG4
-
Output Type:
Fixed
-
Input Voltage:
0.8V~3V
-
Output Voltage:
3V
-
Number of Outputs:
1
-
Switching Frequency:
500kHz
-
Output Current (Max):
1.3A
-
Operating Temperature:
-40°C~+85°C@(TA)
-
Synchronous Rectification:
NO
-
Package:
MSOP-10
-
Manufacturer:
Texas Instruments
-
Series:
-
-
Voltage - Input (Min):
0.8V
-
Base Part Number:
TPS610
-
Current - Output:
1.3A (Switch)
-
Frequency - Switching:
500kHz
-
Part Status:
Active
-
Voltage - Input (Max):
3V
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
10-VSSOP
-
Voltage - Output (Min/Fixed):
3V
-
Package / Case:
10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
-
Voltage - Output (Max):
-
-
Packaging:
Tape & Reel (TR)
-
Output Configuration:
Positive
-
Synchronous Rectifier:
No
-
detail:
Boost Switching Regulator IC Positive Fixed 3V 1 Output 1.3A (Switch) 10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
