ADA4522-4ARZ-RL دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
ADA4522-4ARZ-RL
|
|
حجم فایل
|
96.519
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
28
|
مشخصات فنی
-
RoHS:
true
-
Category:
Operational Amplifier/Comparator/Precision OpAmps
-
Datasheet:
Analog Devices ADA4522-4ARZ-RL
-
Rail to Rail:
轨到轨
-
Number of Circuits:
4
-
-3db Bandwidth(G=1):
6.5MHz
-
Operating Temperature:
-40°C~+125°C
-
Current - Input Bias(Ib):
50pA
-
Gain Bandwidth Product(GBP):
2.7MHz
-
Voltage - Input Offset(Vos):
1.5uV
-
Package:
SOP-14
-
Manufacturer:
Analog Devices
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Amplifier Type:
Zero-Drift
-
Output Type:
Rail-to-Rail
-
Slew Rate:
1.7V/µs
-
Gain Bandwidth Product:
2.7MHz
-
Current - Input Bias:
50pA
-
Voltage - Input Offset:
1.5µV
-
Current - Supply:
830µA
-
Current - Output / Channel:
32mA
-
Voltage - Supply, Single/Dual (±):
4.5V ~ 55V, ±2.25V ~ 27.5V
-
Mounting Type:
Surface Mount
-
Package / Case:
14-SOIC (0.154", 3.90mm Width)
-
Supplier Device Package:
14-SOIC
-
Base Part Number:
ADA4522
-
detail:
Zero-Drift Amplifier 4 Circuit Rail-to-Rail 14-SOIC
