AD7376 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
AD7376
|
|
حجم فایل
|
456.309
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
20
|
مشخصات فنی
-
RoHS:
true
-
Category:
ADC/DAC/Data Conversion/Digital Potentiometers
-
Datasheet:
Analog Devices AD7376ARUZ100-R7
-
Precision:
±30%
-
Interface Type:
SPI
-
Supply Voltage:
4.5V~33V;4.5V~16.5V
-
Number of Channels:
1
-
Operating Temperature:
-40°C~+85°C
-
Resistance Value (Ohms):
100kΩ
-
Temperature Coefficient (Typ):
-300ppm/°C
-
Package:
TSSOP-14
-
Manufacturer:
Analog Devices
-
Series:
iCMOS®
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Taper:
Linear
-
Configuration:
Potentiometer
-
Number of Circuits:
1
-
Number of Taps:
128
-
Resistance (Ohms):
100k
-
Interface:
SPI
-
Memory Type:
Volatile
-
Voltage - Supply:
4.5V ~ 33V, ±4.5V ~ 16.5V
-
Features:
Cascade Pin
-
Tolerance:
±30%
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
14-TSSOP
-
Package / Case:
14-TSSOP (0.173", 4.40mm Width)
-
Resistance - Wiper (Ohms) (Typ):
260
-
Base Part Number:
AD7376
-
detail:
Digital Potentiometer 100k Ohm 1 Circuit 128 Taps SPI Interface 14-TSSOP
