ADG5413BFBCPZ-RL7 دیتاشیت

مشخصات دیتاشیت

دانلود دیتاشیت ADG5413BFBCPZ-RL7	دانلود دیتاشیت

RoHS: true
Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
Datasheet: Analog Devices ADG5413BFBCPZ-RL7
Turn-on time: 500ns
Turn-off time: 515ns
Supply Voltage: 8V~44V
Switch Circuit: SPST(SPST)-Normal Open/Normally closed
Number of Channels: 4
On-State Resistance (Max): 11.5Ω
Package: LFCSP-16-WQ(4x4)
Manufacturer: Analog Devices
Series: -
Packaging: Cut Tape (CT)
Part Status: Active
Multiplexer/Demultiplexer Circuit: 1:1
Number of Circuits: 4
Channel-to-Channel Matching (ΔRon): 50mOhm
Voltage - Supply, Single (V+): 8V ~ 44V
Voltage - Supply, Dual (V±): ±5V ~ 22V
Switch Time (Ton, Toff) (Max): 500ns, 515ns
-3db Bandwidth: 270MHz
Charge Injection: -640pC
Channel Capacitance (CS(off), CD(off)): 12pF, 11pF
Current - Leakage (IS(off)) (Max): 500pA
Crosstalk: -90dB @ 1MHz
Operating Temperature: -40°C ~ 125°C (TA)
Mounting Type: Surface Mount
Package / Case: 16-WQFN Exposed Pad, CSP
Supplier Device Package: 16-LFCSP-WQ (4x4)
Base Part Number: ADG5413
detail: 4 Circuit IC Switch 1:1 11.5Ohm 16-LFCSP-WQ (4x4)
