ADP5080ACBZ-1-RL دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
ADP5080ACBZ-1-RL
|
|
حجم فایل
|
107.183
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
64
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Converters
-
Topology:
Step-down;Boost
-
Datasheet:
Analog Devices ADP5080ACBZ-1-RL
-
Number of Outputs:
9
-
Switching Frequency:
2MHz
-
Operating Temperature:
-20°C~+85°C
-
Package:
WLCSP-72(4x4.5)
-
Manufacturer:
Analog Devices
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Frequency - Switching:
750KHz ~ 2MHz
-
Voltage/Current - Output 1:
0.8V ~ 1.2V, 3A
-
Voltage/Current - Output 2:
1V ~ 3.3V, 1.15A
-
Voltage/Current - Output 3:
1.2V ~ 1.8V, 1.5A
-
w/LED Driver:
No
-
w/Supervisor:
No
-
w/Sequencer:
No
-
Voltage - Supply:
4V ~ 15V
-
Mounting Type:
Surface Mount
-
Package / Case:
72-UFBGA, WLCSP
-
Supplier Device Package:
72-WLCSP (4.46x3.96)
-
Base Part Number:
ADP5080
-
detail:
PMIC - Voltage Regulators - Linear + Switching 9 Output Step-Down (Buck) (6), Step-Up (Boost) (1), Linear (LDO) (3) 750KHz ~ 2MHz 72-WLCSP (4.46x3.96)
