دیتاشیت PIC18F27J53-I/SO
مشخصات دیتاشیت
| نام دیتاشیت | PIC18F47J53 Family |
|---|---|
| حجم فایل | 4843.092 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 564 |
دانلود دیتاشیت PIC18F47J53 Family |
PIC18F47J53 Family Datasheet |
|---|
مشخصات
- RoHS: true
- CPU Core: PIC
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- Watchdog: Yes
- ADC (Bit): 10bit;12bit
- Datasheet: Microchip Tech PIC18F27J53-I/SO
- CPU Maximum Speed: 48MHz
- GPIO Ports Number: 22
- Low-Voltage Detect: Yes
- Internal Oscillator: Yes
- Program Storage Size: 128KB
- Universal Serial Bus: Yes
- Operating Voltage Range: 2.15V~3.6V
- Operating Temperature Range: -40°C~+85°C
- Package: SOP-28-300mil
- Manufacturer: Microchip Tech
- Series: PIC® XLP™ 18J
- Packaging: Tube
- Part Status: Active
- Core Processor: PIC
- Core Size: 8-Bit
- Speed: 48MHz
- Connectivity: I²C, LINbus, SPI, UART/USART, USB
- Peripherals: Brown-out Detect/Reset, POR, PWM, WDT
- Number of I/O: 22
- Program Memory Size: 128KB (64K x 16)
- Program Memory Type: FLASH
- EEPROM Size: -
- RAM Size: 3.8K x 8
- Voltage - Supply (Vcc/Vdd): 2.15V ~ 3.6V
- Data Converters: A/D 10x10b/12b
- Oscillator Type: Internal
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 28-SOIC (0.295", 7.50mm Width)
- Supplier Device Package: 28-SOIC
- Base Part Number: PIC18F27J53
- detail: PIC PIC® XLP™ 18J Microcontroller IC 8-Bit 48MHz 128KB (64K x 16) FLASH 28-SOIC
