دیتاشیت ADP7156ACPZ-3.0-R7

ADP7156 Series

مشخصات دیتاشیت

نام دیتاشیت ADP7156 Series
حجم فایل 636.366 کیلوبایت
نوع فایل pdf
تعداد صفحات 22

دانلود دیتاشیت ADP7156 Series

ADP7156 Series Datasheet

مشخصات

  • Manufacturer: Analog Devices Inc.
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Discontinued at Digi-Key
  • Output Configuration: Positive
  • Output Type: Fixed
  • Number of Regulators: 1
  • Voltage - Input (Max): 5.5V
  • Voltage - Output (Min/Fixed): 3V
  • Voltage - Output (Max): -
  • Voltage Dropout (Max): -
  • Current - Output: 1.2A
  • Current - Quiescent (Iq): 8mA
  • Current - Supply (Max): 12mA
  • PSRR: -
  • Control Features: Enable
  • Protection Features: Over Current, Over Temperature
  • Operating Temperature: -40°C ~ 125°C
  • Mounting Type: Surface Mount
  • Package / Case: 10-VFDFN Exposed Pad, CSP
  • Supplier Device Package: 10-LFCSP-WD (3x3)
  • Base Part Number: ADP7156
  • detail: Linear Voltage Regulator IC 1 Output 1.2A 10-LFCSP-WD (3x3)
