SN74AHC8541N دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت SN74AHC8541N	دانلود دیتاشیت

RoHS: true
Category: Logic ICs/Buffer/Driver/Transceiver
Datasheet: Texas Instruments SN74AHC8541N
Input type: Schmitt Trigger
output type: Tri-State
Logic Family: 74AHC
Sink Current: 12mA
Source Current: 12mA
Supply Voltage: 2V~5.5V
Number of Elements: 1
Operating Temperature: -40°C~+85°C
Number of Bits per Element: 8
Package: PDIP-20
Manufacturer: Texas Instruments
Series: 74AHC
Package / Case: 20-DIP (0.300", 7.62mm)
Supplier Device Package: 20-PDIP
Part Status: Active
Current - Output High, Low: 12mA, 12mA
Mounting Type: Through Hole
Base Part Number: SN74AHC8
Voltage - Supply: 2V ~ 5.5V
Packaging: Tube
Logic Type: Buffer, Inverting, Non-Inverting
detail: Buffer, Inverting, Non-Inverting 1 Element 8 Bit per Element 3-State Output 20-PDIP
