ADG5243FBCPZ-RL7 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
ADG5243FBCPZ-RL7
|
|
حجم فایل
|
110.14
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
30
|
مشخصات فنی
-
RoHS:
true
-
Category:
Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
-
Datasheet:
Analog Devices ADG5243FBCPZ-RL7
-
Turn-on time:
215ns
-
Turn-off time:
85ns
-
Supply Voltage:
8V~44V
-
Switch Circuit:
SPDT(SPDT)
-
Number of Channels:
3
-
On-State Resistance (Max):
335Ω
-
Package:
LFCSP-20
-
Manufacturer:
Analog Devices
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Multiplexer/Demultiplexer Circuit:
2:1
-
Number of Circuits:
3
-
Channel-to-Channel Matching (ΔRon):
3Ohm
-
Voltage - Supply, Single (V+):
8V ~ 44V
-
Voltage - Supply, Dual (V±):
±5V ~ 22V
-
Switch Time (Ton, Toff) (Max):
215ns, 85ns
-
-3db Bandwidth:
350MHz
-
Charge Injection:
-1.4pC
-
Channel Capacitance (CS(off), CD(off)):
-
-
Current - Leakage (IS(off)) (Max):
1nA
-
Crosstalk:
-85dB @ 1MHz
-
Operating Temperature:
-40°C ~ 125°C (TA)
-
Mounting Type:
Surface Mount
-
Package / Case:
20-WFQFN Exposed Pad, CSP
-
Supplier Device Package:
20-LFCSP (4x4)
-
Base Part Number:
ADG5243
-
detail:
3 Circuit IC Switch 2:1 335Ohm 20-LFCSP (4x4)
