دیتاشیت AT89C51CC02UA-TISUM

مشخصات دیتاشیت

دانلود دیتاشیت AT89C51CC02,T89C51CC02	AT89C51CC02,T89C51CC02 Datasheet

RoHS: true
CPU Core: 51Series
Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
Watchdog: Yes
ADC (Bit): 10bit
Datasheet: Microchip Tech AT89C51CC02UA-TISUM
CPU Maximum Speed: 40MHz
GPIO Ports Number: 20
Low-Voltage Detect: Yes
Program Storage Size: 16KB
Operating Voltage Range: 3V~5.5V
Operating Temperature Range: -40°C~+85°C
Package: SOP-28-300mil
Manufacturer: Microchip Tech
Series: AT89C CAN
Packaging: Tube
Part Status: Active
Core Processor: 80C51
Core Size: 8-Bit
Speed: 40MHz
Connectivity: CANbus, UART/USART
Peripherals: POR, PWM, WDT
Number of I/O: 20
Program Memory Size: 16KB (16K x 8)
Program Memory Type: FLASH
EEPROM Size: 2K x 8
RAM Size: 512 x 8
Voltage - Supply (Vcc/Vdd): 3V ~ 5.5V
Data Converters: A/D 8x10b
Oscillator Type: External
Operating Temperature: -40°C ~ 85°C (TA)
Mounting Type: Surface Mount
Package / Case: 28-SOIC (0.295", 7.50mm Width)
Supplier Device Package: 28-SOIC
Base Part Number: AT89C51CC02
detail: 80C51 AT89C CAN Microcontroller IC 8-Bit 40MHz 16KB (16K x 8) FLASH 28-SOIC
