ADP7185ACPZN1.0-R7 دیتاشیت

ADP7185ACPZN1.0-R7

مشخصات دیتاشیت

نام دیتاشیت ADP7185ACPZN1.0-R7
حجم فایل 108.018 کیلوبایت
نوع فایل pdf
تعداد صفحات 19

دانلود دیتاشیت ADP7185ACPZN1.0-R7

دانلود دیتاشیت

سایر مستندات

ADP7185 Datasheet 19 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: Analog Devices ADP7185ACPZN1.0-R7
  • Output Current: 500mA
  • Output Voltage: 1V~1V
  • Dropout Voltage: 0.36V@(500mA)
  • Output Polarity: Negative
  • Number of Outputs: 1
  • Maximum Input Voltage: 5.5V
  • Operating Temperature: -40°C~+125°C@(Tj)
  • Quiescent Current (Ground Current): 900uA
  • Package: LFCSP-8
  • Manufacturer: Analog Devices
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Discontinued at Digi-Key
  • Output Configuration: Negative
  • Output Type: Fixed
  • Number of Regulators: 1
  • Voltage - Input (Max): -5.5V
  • Voltage - Output (Min/Fixed): -1V
  • Voltage - Output (Max): -
  • Voltage Dropout (Max): 0.36V @ 500mA
  • Current - Output: 500mA
  • Current - Quiescent (Iq): 900µA
  • Current - Supply (Max): 7mA
  • PSRR: 80dB ~ 40dB (1kHz ~ 1MHz)
  • Control Features: Enable, Power On Reset
  • Protection Features: Over Current
  • Mounting Type: Surface Mount
  • Package / Case: 8-UFDFN Exposed Pad, CSP
  • Supplier Device Package: 8-LFCSP (2x2)
  • Base Part Number: ADP7185
  • detail: Linear Voltage Regulator IC 1 Output 500mA 8-LFCSP (2x2)
