SN74LVCZ16240ADGGR دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | SN74LVCZ16240ADGGR |
|---|---|
| حجم فایل | 102.196 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 13 |
دانلود دیتاشیت SN74LVCZ16240ADGGR |
دانلود دیتاشیت |
|---|
سایر مستندات
SN74LVCZ16240A 10 pages
مشخصات فنی
- RoHS: true
- Category: Logic ICs/Buffer/Driver/Transceiver
- Datasheet: Texas Instruments SN74LVCZ16240ADGGR
- output type: Tri-State
- Logic Family: 74LVCZ
- Sink Current: 24mA
- Source Current: 24mA
- Supply Voltage: 2.7V~3.6V
- Number of Elements: 4
- Operating Temperature: -40°C~+85°C
- Number of Bits per Element: 4
- Package: TSSOP-48
- Manufacturer: Texas Instruments
- Series: 74LVCZ
- Package / Case: 48-TFSOP (0.240", 6.10mm Width)
- Supplier Device Package: 48-TSSOP
- Part Status: Active
- Current - Output High, Low: 24mA, 24mA
- Mounting Type: Surface Mount
- Base Part Number: SN74LVCZ1
- Voltage - Supply: 2.7V ~ 3.6V
- Packaging: Cut Tape (CT)
- Input Type: -
- Logic Type: Buffer, Inverting
- detail: Buffer, Inverting 4 Element 4 Bit per Element 3-State Output 48-TSSOP
