- دیتاشیت Signal e-Book: OP Amp Design Topics
دیتاشیت Signal e-Book: OP Amp Design Topics
مشخصات دیتاشیت
| نام دیتاشیت | Signal e-Book: OP Amp Design Topics |
|---|---|
| حجم فایل | 17975.467 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 37 |
Signal e-Book: OP Amp Design Topics |
دانلود دیتاشیت |
|---|
سایر مستندات
LMH6609MF/NOPB 30 pages
LMH6609 Datasheet 29 pages
مشخصات فنی
- RoHS: true
- Category: Operational Amplifier/Comparator/Operational Amplifier
- Datasheet: Texas Instruments LMH6609 MDC
- -3db Bandwidth: 900MHz
- Output Current: 90mA
- Number of Circuits: 1
- Operating Temperature: -40°C~+85°C
- Current - Input Bias(Ib): 2uA
- Gain Bandwidth Product(GBP): -
- Package: -
- Manufacturer: Texas Instruments
- Series: VIP10™
- Package / Case: Die
- Current - Supply: 7mA
- Voltage - Input Offset: 800µV
- Mounting Type: Surface Mount
- Part Status: Active
- Slew Rate: 1400V/µs
- Voltage - Supply, Single/Dual (±): 6V ~ 12V, ±3V ~ 6V
- Amplifier Type: Voltage Feedback
- Current - Output / Channel: 90mA
- Packaging: Tube
- Base Part Number: LMH6609
- Current - Input Bias: 2µA
- Output Type: -
- Supplier Device Package: Diesale
- detail: Voltage Feedback Amplifier 1 Circuit Diesale
