دیتاشیت ADW54010Z-0REEL

ADG736

مشخصات دیتاشیت

نام دیتاشیت ADG736
حجم فایل 249.184 کیلوبایت
نوع فایل pdf
تعداد صفحات 12

دانلود دیتاشیت ADG736

ADG736 Datasheet

مشخصات

  • Manufacturer: Analog Devices Inc.
  • Series: Automotive
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Switch Circuit: SPDT
  • Multiplexer/Demultiplexer Circuit: 2:1
  • Number of Circuits: 2
  • On-State Resistance (Max): 4Ohm
  • Channel-to-Channel Matching (ΔRon): 100mOhm
  • Voltage - Supply, Single (V+): 1.8V ~ 5.5V
  • Voltage - Supply, Dual (V±): -
  • Switch Time (Ton, Toff) (Max): 12ns, 5ns (Typ)
  • -3db Bandwidth: 200MHz
  • Charge Injection: -
  • Channel Capacitance (CS(off), CD(off)): 9pF
  • Current - Leakage (IS(off)) (Max): 10pA (Typ)
  • Crosstalk: -82dB @ 1MHz
  • Operating Temperature: -40°C ~ 125°C (TA)
  • Mounting Type: Surface Mount
  • Package / Case: 10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
  • Supplier Device Package: 10-MSOP
  • Base Part Number: ADW54010
  • detail: 2 Circuit IC Switch 2:1 4Ohm 10-MSOP
