- دیتاشیت ADUM1441ARQZ-RL7
ADUM1441ARQZ-RL7 دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | ADUM1441ARQZ-RL7 |
|---|---|
| حجم فایل | 125.594 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 25 |
دانلود دیتاشیت ADUM1441ARQZ-RL7 |
دانلود دیتاشیت |
|---|
سایر مستندات
ADUM144x Datasheet 25 pages
مشخصات فنی
- RoHS: true
- Category: Communication Interface Chip/UART/485/232/Digital Isolators
- Data Rate: 2Mbps
- Datasheet: Analog Devices ADUM1441ARQZ-RL7
- Applications: -
- Supply Voltage: 2.25V~3.6V
- Forward Channel: 3
- Reverse channel: 1
- Number of Channels: 4
- Isolation Technology: Magnetic isolation
- Operating Temperature: -
- Voltage Isolation or Not: 带电压隔离
- Package: QSOP-16-150mil
- Manufacturer: Analog Devices
- Series: iCoupler®
- Packaging: Cut Tape (CT)
- Part Status: Active
- Technology: Magnetic Coupling
- Type: General Purpose
- Isolated Power: No
- Inputs - Side 1/Side 2: 3/1
- Channel Type: Unidirectional
- Voltage - Isolation: 2500Vrms
- Common Mode Transient Immunity (Min): 25kV/µs
- Propagation Delay tpLH / tpHL (Max): 180ns, 180ns
- Pulse Width Distortion (Max): 8ns
- Rise / Fall Time (Typ): 2ns, 2ns
- Voltage - Supply: 2.25V ~ 3.6V
- Mounting Type: Surface Mount
- Package / Case: 16-SSOP (0.154", 3.90mm Width)
- Supplier Device Package: 16-QSOP
- Base Part Number: ADUM1441
- detail: General Purpose Digital Isolator 2500Vrms 4 Channel 2Mbps 25kV/µs CMTI 16-SSOP (0.154", 3.90mm Width)
