دیتاشیت LM3209TLE-G3/NOPB
مشخصات دیتاشیت
| نام دیتاشیت | LM3209-G3 Datasheet |
|---|---|
| حجم فایل | 1464.472 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 22 |
دانلود دیتاشیت LM3209-G3 Datasheet |
LM3209-G3 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Function: Buck-boost type
- Topology: Step-down-Boost
- Datasheet: Texas Instruments LM3209TLE-G3/NOPB
- Output Type: Adjustable
- Input Voltage: 2.7V~5.5V
- Output Voltage: 0.6V~4.2V
- Number of Outputs: 1
- Switching Frequency: 2.4MHz
- Output Current (Max): 650mA
- Operating Temperature: -30°C~+85°C@(TA)
- Synchronous Rectification: Yes
- Package: DSBGA-12(2x2.5)
- Manufacturer: Texas Instruments
- Series: -
- Voltage - Input (Min): 2.7V
- Base Part Number: LM3209
- Current - Output: 650mA
- Frequency - Switching: 2.4MHz
- Part Status: Active
- Voltage - Input (Max): 5.5V
- Mounting Type: Surface Mount
- Supplier Device Package: 12-DSBGA (2x2.5)
- Voltage - Output (Min/Fixed): 0.6V
- Package / Case: 12-WFBGA, DSBGA
- Voltage - Output (Max): 4.2V
- Packaging: Cut Tape (CT)
- Output Configuration: Positive
- Synchronous Rectifier: Yes
- detail: Buck-Boost Switching Regulator IC Positive Adjustable 0.6V 1 Output 650mA 12-WFBGA, DSBGA
