ADGS1412BCPZ-RL7 دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت ADGS1412BCPZ-RL7	دانلود دیتاشیت

ADGS1412 27 pages

RoHS: true
Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
Datasheet: Analog Devices ADGS1412BCPZ-RL7
Turn-on time: 135ns
Turn-off time: 190ns
Supply Voltage: 5V~20V
Switch Circuit: SPST(SPST)-Normal Open
Number of Channels: 4
On-State Resistance (Max): 1.8Ω
Package: LFCSP-24
Manufacturer: Analog Devices
Series: -
Packaging: Cut Tape (CT)
Part Status: Active
Multiplexer/Demultiplexer Circuit: 1:1
Number of Circuits: 4
Channel-to-Channel Matching (ΔRon): 100mOhm
Voltage - Supply, Single (V+): 5V ~ 20V
Voltage - Supply, Dual (V±): ±4.5V ~ 16.5V
Switch Time (Ton, Toff) (Max): 135ns, 190ns
-3db Bandwidth: 170MHz
Charge Injection: -20pC
Channel Capacitance (CS(off), CD(off)): 22pF, 23pF
Current - Leakage (IS(off)) (Max): 550pA
Crosstalk: -100dB @ 1MHz
Operating Temperature: -40°C ~ 125°C (TA)
Mounting Type: Surface Mount
Package / Case: 24-VFQFN Exposed Pad, CSP
Supplier Device Package: 24-LFCSP (4x4)
Base Part Number: ADGS1412
detail: 4 Circuit IC Switch 1:1 1.8Ohm 24-LFCSP (4x4)
