دیتاشیت ADG1208YCPZ-REEL7

مشخصات دیتاشیت

دانلود دیتاشیت ADG1208,09	ADG1208,09 Datasheet

RoHS: true
Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
Datasheet: Analog Devices ADG1208YCPZ-REEL7
Turn-on time: 95ns
Turn-off time: 100ns
Supply Voltage: 5V~16.5V
Number of Channels: 1
On-State Resistance (Max): 200Ω
Package: LFCSP-16
Manufacturer: Analog Devices
Series: -
Packaging: Cut Tape (CT)
Part Status: Active
Switch Circuit: -
Multiplexer/Demultiplexer Circuit: 8:1
Number of Circuits: 1
Channel-to-Channel Matching (ΔRon): 3.5Ohm
Voltage - Supply, Single (V+): 5V ~ 16.5V
Voltage - Supply, Dual (V±): ±5V ~ 16.5V
Switch Time (Ton, Toff) (Max): 95ns, 100ns
-3db Bandwidth: 550MHz
Charge Injection: 0.4pC
Channel Capacitance (CS(off), CD(off)): 1.5pF, 7pF
Current - Leakage (IS(off)) (Max): 100pA
Crosstalk: -85dB @ 1MHz
Operating Temperature: -40°C ~ 125°C (TA)
Mounting Type: Surface Mount
Package / Case: 16-VQFN Exposed Pad, CSP
Supplier Device Package: 16-LFCSP-VQ (4x4)
Base Part Number: ADG1208
detail: 1 Circuit IC Switch 8:1 200Ohm 16-LFCSP-VQ (4x4)
