- دیتاشیت AT89C51AC3
AT89C51AC3 دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | AT89C51AC3 |
|---|---|
| حجم فایل | 1413.901 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 140 |
دانلود دیتاشیت AT89C51AC3 |
دانلود دیتاشیت |
|---|
سایر مستندات
AT89C51AC3 Errata 2 pages
AT89C51AC3-RLTUM 140 pages
مشخصات فنی
- RoHS: true
- CPU Core: 51Series
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- ADC (Bit): 10bit
- Datasheet: Microchip Tech AT89C51AC3-S3SUM
- CPU Maximum Speed: 60MHz
- GPIO Ports Number: 36
- Direct Memory Access: -
- Universal Serial Bus: -
- Operating Voltage Range: 3V~5.5V
- Operating Temperature Range: -40°C~+85°C
- Secure Digital Input and Output: -
- Package: PLCC-52
- Manufacturer: Microchip Tech
- Series: 89C
- Packaging: Tube
- Part Status: Active
- Core Processor: 80C51
- Core Size: 8-Bit
- Speed: 60MHz
- Connectivity: SPI, UART/USART
- Peripherals: POR, PWM, WDT
- Number of I/O: 36
- Program Memory Size: 64KB (64K x 8)
- Program Memory Type: FLASH
- EEPROM Size: 2K x 8
- RAM Size: 2.25K x 8
- Voltage - Supply (Vcc/Vdd): 3V ~ 5.5V
- Data Converters: A/D 8x10b
- Oscillator Type: External
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 52-LCC (J-Lead)
- Supplier Device Package: 52-PLCC (19.15x19.15)
- Base Part Number: AT89C51AC3
- detail: 80C51 89C Microcontroller IC 8-Bit 60MHz 64KB (64K x 8) FLASH 52-PLCC (19.15x19.15)
