دیتاشیت ADUC7020BCPZ62-RL7
مشخصات دیتاشیت
| نام دیتاشیت | ADUC7019-29 |
|---|---|
| حجم فایل | 1835.99 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 102 |
دانلود دیتاشیت ADUC7019-29 |
ADUC7019-29 Datasheet |
|---|
مشخصات
- RoHS: true
- EEPROM: -
- CPU Core: ARMOther series
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- RAM Size: 8KB
- Watchdog: Yes
- ADC (Bit): 12bit
- DAC (Bit): 12bit
- Datasheet: Analog Devices ADUC7020BCPZ62-RL7
- PWM (Bit): -
- Real-Time Clock: -
- CPU Maximum Speed: 44MHz
- GPIO Ports Number: 14
- Low-Voltage Detect: -
- CCP Capture/Compare: -
- Internal Comparator: -
- Internal Oscillator: Yes
- Peripheral/Function: PWM;On-chip temperature sensor;WDT
- Program Memory Type: FLASH
- Direct Memory Access: -
- Program Storage Size: 62KB
- Universal Serial Bus: -
- communication protocol: -
- Operating Voltage Range: 2.7V~3.6V
- Infrared Data Association: -
- Operating Temperature Range: -40°C~+125°C
- Secure Digital Input and Output: -
- Package: LFCSP-VQ-40
- Manufacturer: Analog Devices
- Series: MicroConverter® ADuC7xxx
- Packaging: Cut Tape (CT)
- Part Status: Active
- Core Processor: ARM7®
- Core Size: 16/32-Bit
- Speed: 44MHz
- Connectivity: EBI/EMI, I²C, SPI, UART/USART
- Peripherals: PLA, PWM, PSM, Temp Sensor, WDT
- Number of I/O: 14
- Program Memory Size: 62KB (31K x16)
- EEPROM Size: -
- Voltage - Supply (Vcc/Vdd): 2.7V ~ 3.6V
- Data Converters: A/D 5x12b; D/A 4x12b
- Oscillator Type: Internal
- Operating Temperature: -40°C ~ 125°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 40-VFQFN Exposed Pad, CSP
- Supplier Device Package: 40-LFCSP-VQ (6x6)
- Base Part Number: ADUC7020
- detail: ARM7® MicroConverter® ADuC7xxx Microcontroller IC 16/32-Bit 44MHz 62KB (31K x16) FLASH 40-LFCSP-VQ (6x6)
