دیتاشیت ADP2384ACPZN-R7
مشخصات دیتاشیت
| نام دیتاشیت |
ADP2384
|
| حجم فایل |
708.264
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
24
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Converters
-
Function:
Step-down type
-
Topology:
Step-down
-
Datasheet:
Analog Devices ADP2384ACPZN-R7
-
Output Type:
Adjustable
-
Input Voltage:
4.5V~20V
-
Output Voltage:
0.6V~18V
-
Number of Outputs:
1
-
Switching Frequency:
1.4MHz
-
Output Current (Max):
4A
-
Operating Temperature:
-40°C~+125°C@(TJ)
-
Synchronous Rectification:
Yes
-
Package:
LFCSP-24
-
Manufacturer:
Analog Devices
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Output Configuration:
Positive
-
Voltage - Input (Min):
4.5V
-
Voltage - Input (Max):
20V
-
Voltage - Output (Min/Fixed):
0.6V
-
Voltage - Output (Max):
18V
-
Current - Output:
4A
-
Frequency - Switching:
200kHz ~ 1.4MHz
-
Synchronous Rectifier:
Yes
-
Mounting Type:
Surface Mount
-
Package / Case:
24-WFQFN Exposed Pad, CSP
-
Supplier Device Package:
24-LFCSP-WQ (4x4)
-
Base Part Number:
ADP2384
-
detail:
Buck Switching Regulator IC Positive Adjustable 0.6V 1 Output 4A 24-WFQFN Exposed Pad, CSP
