دیتاشیت ATWINC1510-MR210UB1954

مشخصات دیتاشیت

دانلود دیتاشیت ATWINC15x0-MR210xBB	ATWINC15x0-MR210xBB Datasheet

RoHS: true
Category: Radio Frequency Chip/Antenna/RF Transceiver ICs
Datasheet: Microchip Tech ATWINC1510-MR210UB1954
Package: SMD-28P
Manufacturer: Microchip Tech
Series: -
Packaging: Tray
Part Status: Active
RF Family/Standard: WiFi
Protocol: 802.11b/g/n
Modulation: 16-QAM, 64-QAM, BPSK, CCK, DBPSK, DQPSK, OFDM, QPSK
Frequency: 2.4GHz
Data Rate: 72.2Mbps
Power - Output: 19.5dBm
Sensitivity: -98dBm
Serial Interfaces: I²C, SPI, UART
Antenna Type: Antenna Not Included, U.FL
Utilized IC / Part: -
Memory Size: 8MB Flash, 128kB RAM
Voltage - Supply: 3V ~ 4.2V
Current - Receiving: 52.5mA ~ 70.1mA
Current - Transmitting: 132mA ~ 294mA
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 85°C
Package / Case: Module
Firmware Version: 19.4.4
detail: WiFi 802.11b/g/n Transceiver Module 2.4GHz Antenna Not Included, U.FL Surface Mount
