دیتاشیت ADCMP582BCPZ-R2
مشخصات دیتاشیت
| نام دیتاشیت |
ADCMP580-582
|
| حجم فایل |
411.884
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
16
|
مشخصات
-
RoHS:
true
-
Category:
Operational Amplifier/Comparator/Comparators
-
Datasheet:
Analog Devices ADCMP582BCPZ-R2
-
Output Type:
互补;PECL
-
Supply Voltage:
4.5V~5.5V
-
Number of Elements:
-
-
Operating Temperature:
-40°C~+125°C
-
Input Bias Current (Ib):
30uA
-
Input Offset Voltage (Vos):
10mV
-
Input Hysteresis Voltage (Vhys):
1mV
-
Common Mode Rejection Ratio (CMRR):
60dB
-
Package:
LFCSP-16
-
Manufacturer:
Analog Devices
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Type:
with Latch
-
Voltage - Supply, Single/Dual (±):
±4.5V ~ 5.5V
-
Voltage - Input Offset (Max):
10mV @ ±5V
-
Current - Input Bias (Max):
30µA @ ±5V
-
Current - Output (Typ):
44mA @ 5V
-
Current - Quiescent (Max):
8mA
-
CMRR, PSRR (Typ):
60dB CMRR, 75dB PSRR
-
Propagation Delay (Max):
0.18ns
-
Hysteresis:
1mV
-
Package / Case:
16-WFQFN Exposed Pad, CSP
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
16-LFCSP (3x3)
-
Base Part Number:
ADCMP582
-
detail:
Comparator with Latch Complementary, PECL 16-LFCSP (3x3)
