دیتاشیت AD5724RBREZ-REEL7

AD5724,34,54R

مشخصات دیتاشیت

نام دیتاشیت AD5724,34,54R
حجم فایل 1577.148 کیلوبایت
نوع فایل pdf
تعداد صفحات 33

دانلود دیتاشیت AD5724,34,54R

AD5724,34,54R Datasheet

مشخصات

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Digital To Analog Converters (DACs)
  • Datasheet: Analog Devices AD5724RBREZ-REEL7
  • Interface: SPI;DSP
  • Resolution: 12Bit
  • Output Type: Voltage-缓冲
  • Settling Time: 12us
  • Supply Voltage: 2.7V~5.5V
  • Integral nonlinearity: ±1LSB
  • Operating Temperature: -40°C~+85°C
  • Package: TSSOP-24
  • Manufacturer: Analog Devices
  • Series: iCMOS®
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Number of Bits: 12
  • Number of D/A Converters: 4
  • Differential Output: No
  • Data Interface: SPI, DSP
  • Reference Type: External, Internal
  • Voltage - Supply, Analog: ±4.5V ~ 16.5V
  • Voltage - Supply, Digital: 2.7V ~ 5.5V
  • INL/DNL (LSB): ±1 (Max), ±1 (Max)
  • Architecture: String DAC
  • Package / Case: 24-TSSOP (0.173", 4.40mm Width) Exposed Pad
  • Supplier Device Package: 24-TSSOP-EP
  • Mounting Type: Surface Mount
  • Base Part Number: AD5724
  • detail: 12 Bit Digital to Analog Converter 4 24-TSSOP-EP
