AD7655ASTZ دیتاشیت

AD7655ASTZ

مشخصات دیتاشیت

نام دیتاشیت AD7655ASTZ
حجم فایل 101.183 کیلوبایت
نوع فایل pdf
تعداد صفحات 26

دانلود دیتاشیت AD7655ASTZ

دانلود دیتاشیت

سایر مستندات

AD7655 26 pages

مشخصات فنی

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
  • Datasheet: Analog Devices AD7655ASTZRL
  • Interface: SPI;Parallel;DSP
  • resolution: 16Bit
  • Supply Voltage: 5V
  • number of channels: 2;4
  • sampling frequency: 1MHz
  • Operating Temperature: -40°C~+85°C
  • Package: LQFP-48(7x7)
  • Manufacturer: Analog Devices
  • Series: PulSAR®
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Number of Bits: 16
  • Sampling Rate (Per Second): 1M
  • Number of Inputs: 2, 4
  • Input Type: Pseudo-Differential, Single Ended
  • Data Interface: SPI, Parallel, DSP
  • Configuration: MUX-S/H-MUX-ADC
  • Ratio - S/H:ADC: 2:1
  • Number of A/D Converters: 1
  • Architecture: SAR
  • Reference Type: External
  • Voltage - Supply, Analog: 5V
  • Voltage - Supply, Digital: 5V
  • Features: Simultaneous Sampling
  • Package / Case: 48-LQFP
  • Supplier Device Package: 48-LQFP (7x7)
  • Mounting Type: Surface Mount
  • Base Part Number: AD7655
  • detail: 16 Bit Analog to Digital Converter 2, 4 Input 1 SAR 48-LQFP (7x7)
