SN74HCT646DW دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | SN74HCT646DW |
|---|---|
| حجم فایل | 99.465 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 11 |
دانلود دیتاشیت SN74HCT646DW |
دانلود دیتاشیت |
|---|
سایر مستندات
SN54HCT646, SN74HCT646 10 pages
مشخصات فنی
- RoHS: true
- Category: Logic ICs/Buffer/Driver/Transceiver
- Datasheet: Texas Instruments SN74HCT646DW
- output type: Tri-State
- Logic Family: 74HCT
- Sink Current: 6mA
- Source Current: 6mA
- Supply Voltage: 4.5V~5.5V
- Number of Elements: 1
- Operating Temperature: -40°C~+85°C
- Number of Bits per Element: 8
- Package: SOP-24-300mil
- Manufacturer: Texas Instruments
- Series: 74HCT
- Package / Case: 24-SOIC (0.295", 7.50mm Width)
- Supplier Device Package: 24-SOIC
- Part Status: Active
- Current - Output High, Low: 6mA, 6mA
- Mounting Type: Surface Mount
- Base Part Number: SN74HCT
- Voltage - Supply: 4.5V ~ 5.5V
- Packaging: Tube
- Input Type: -
- Logic Type: Transceiver, Non-Inverting
- detail: Transceiver, Non-Inverting 1 Element 8 Bit per Element 3-State Output 24-SOIC
