دیتاشیت ADP2311ACPZ-4-R7
مشخصات دیتاشیت
| نام دیتاشیت | ADP2311 Datasheet |
|---|---|
| حجم فایل | 698.198 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 20 |
دانلود دیتاشیت ADP2311 Datasheet |
ADP2311 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Function: Step-down type
- Topology: Step-down
- Datasheet: Analog Devices ADP2311ACPZ-4-R7
- Output Type: Adjustable
- Input Voltage: 4.5V~18V
- Output Voltage: 0.6V~18V
- Number of Outputs: 2
- Switching Frequency: 300kHz
- Output Current (Max): 1A
- Operating Temperature: -40°C~+125°C@(TJ)
- Synchronous Rectification: Yes
- Package: LFCSP-24
- Manufacturer: Analog Devices
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Output Configuration: Positive
- Voltage - Input (Min): 4.5V
- Voltage - Input (Max): 18V
- Voltage - Output (Min/Fixed): 0.6V
- Voltage - Output (Max): 18V
- Current - Output: 1A
- Frequency - Switching: 300kHz
- Synchronous Rectifier: Yes
- Mounting Type: Surface Mount
- Package / Case: 24-WFQFN Exposed Pad, CSP
- Supplier Device Package: 24-LFCSP-WQ (4x4)
- Base Part Number: ADP2311
- detail: Buck Switching Regulator IC Positive Adjustable 0.6V 2 Output 1A 24-WFQFN Exposed Pad, CSP
