TLV3701QDBVREP دیتاشیت

TLV3701QDBVREP

مشخصات دیتاشیت

نام دیتاشیت TLV3701QDBVREP
حجم فایل 76.984 کیلوبایت
نوع فایل pdf
تعداد صفحات 12

مشاهده دیتاشیت TLV3701QDBVREP

دانلود دیتاشیت

سایر مستندات

TLV3701-EP 11 pages

مشخصات فنی

  • RoHS: true
  • Category: Operational Amplifier/Comparator/Comparators
  • Datasheet: Texas Instruments TLV3701QDBVREP
  • Output Type: Push Pull
  • Supply Voltage: 2.7V~16V;1.35V~8V
  • Number of Elements: -
  • Operating Temperature: -40°C~+125°C
  • Input Bias Current (Ib): 250pA
  • Input Offset Voltage (Vos): 5mV
  • Input Hysteresis Voltage (Vhys): -
  • Common Mode Rejection Ratio (CMRR): 85dB
  • Package: SOT-23-5
  • Manufacturer: Texas Instruments
  • Series: -
  • Type: General Purpose
  • Package / Case: SC-74A, SOT-753
  • Voltage - Input Offset (Max): 5mV @ 5V
  • Current - Output (Typ): 10mA
  • Part Status: Active
  • Base Part Number: TLV370
  • Mounting Type: Surface Mount
  • Voltage - Supply, Single/Dual (±): 2.7V ~ 16V, ±1.35V ~ 8V
  • Propagation Delay (Max): 240µs
  • Current - Input Bias (Max): 250pA @ 5V
  • Hysteresis: -
  • Packaging: Cut Tape (CT)
  • CMRR, PSRR (Typ): 88dB CMRR, 105dB PSRR
  • Current - Quiescent (Max): 1.2µA
  • Supplier Device Package: SOT-23-5
  • detail: Comparator General Purpose CMOS, Push-Pull, Rail-to-Rail SOT-23-5
