DAC7551ZTDRNRQ1 数据手册
其他文档
DAC7551-Q1 27 pages
技术规格
- RoHS: true
- Category: ADC/DAC/Data Conversion/Digital To Analog Converters (DACs)
- Datasheet: Texas Instruments DAC7551ZTDRNRQ1
- Package: DFN-12-EP(2x3)
- Manufacturer: Texas Instruments
- Series: Automotive, AEC-Q100
- Voltage - Supply, Digital: 2.7V ~ 5.5V
- Voltage - Supply, Analog: 2.7V ~ 5.5V
- INL/DNL (LSB): ±0.35, ±0.08
- Supplier Device Package: 12-USON (3x2)
- Package / Case: 12-UFDFN Exposed Pad
- Number of Bits: 12
- Differential Output: No
- Part Status: Active
- Reference Type: External
- Settling Time: 5µs
- Mounting Type: Surface Mount
- Operating Temperature: -40°C ~ 105°C
- Architecture: String DAC
- Output Type: Voltage - Buffered
- Number of D/A Converters: 1
- Packaging: Cut Tape (CT)
- Base Part Number: DAC7551
- Data Interface: SPI, DSP
- detail: 12 Bit Digital to Analog Converter 1 12-USON (3x2)
