OPA336, 2336, 4336 Datasheet

OPA336, 2336, 4336

Datasheet specifications

Datasheet's name OPA336, 2336, 4336
File size 1937.321 KB
File type pdf
Number of pages 29

Download Datasheet OPA336, 2336, 4336

Download Datasheet

Other documentations

OPA336NA/250 27 pages

Technical specifications

  • RoHS: true
  • Category: Operational Amplifier/Comparator/Operational Amplifier
  • Datasheet: Texas Instruments OPA2336U/2K5
  • Rail to Rail: 轨到轨
  • -3db Bandwidth: -
  • Output Current: 5mA
  • Operating Temperature: -40°C~+85°C
  • Current - Input Bias(Ib): 1pA
  • Gain Bandwidth Product(GBP): 100kHz
  • Package: SOP-8
  • Manufacturer: Texas Instruments
  • Series: MicroAmplifier™
  • Package / Case: 8-SOIC (0.154", 3.90mm Width)
  • Number of Circuits: 2
  • Current - Supply: 20µA
  • Voltage - Input Offset: 60µV
  • Mounting Type: Surface Mount
  • Part Status: Active
  • Slew Rate: 0.03V/µs
  • Voltage - Supply, Single/Dual (±): 2.3V ~ 5.5V
  • Gain Bandwidth Product: 100kHz
  • Amplifier Type: General Purpose
  • Current - Output / Channel: 5mA
  • Packaging: Tape & Reel (TR)
  • Base Part Number: OPA233
  • Current - Input Bias: 1pA
  • Output Type: Rail-to-Rail
  • Supplier Device Package: 8-SOIC
  • detail: General Purpose Amplifier 2 Circuit Rail-to-Rail 8-SOIC
