ADUM5401WCRWZ-1RL دیتاشیت

مشخصات دیتاشیت

دانلود دیتاشیت ADUM5401WCRWZ-1RL	دانلود دیتاشیت

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Datasheet: Analog Devices ADUM5401WCRWZ-1RL
Package: SOIC-16
Manufacturer: Analog Devices
Series: Automotive
Packaging: Cut Tape (CT)
Part Status: Active
Technology: Magnetic Coupling
Type: General Purpose
Isolated Power: Yes
Number of Channels: 4
Inputs - Side 1/Side 2: 3/1
Channel Type: Unidirectional
Voltage - Isolation: 2500Vrms
Common Mode Transient Immunity (Min): 25kV/µs
Data Rate: 25Mbps
Propagation Delay tpLH / tpHL (Max): 60ns, 60ns
Pulse Width Distortion (Max): 6ns
Rise / Fall Time (Typ): 2.5ns, 2.5ns
Voltage - Supply: 3V ~ 5.5V
Operating Temperature: -40°C ~ 105°C
Mounting Type: Surface Mount
Package / Case: 16-SOIC (0.295", 7.50mm Width)
Supplier Device Package: 16-SOIC
Base Part Number: ADUM5401
detail: General Purpose Digital Isolator 2500Vrms 4 Channel 25Mbps 25kV/µs CMTI 16-SOIC (0.295", 7.50mm Width)
