AD9635BCPZ-80 Datasheet
Datasheet specifications
| Datasheet's name | AD9635 |
|---|---|
| File size | 966.327 KB |
| File type | |
| Number of pages | 36 |
Download Datasheet AD9635 |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Manufacturer: Analog Devices Inc.
- Series: -
- Packaging: Tray
- Part Status: Active
- Number of Bits: 12
- Sampling Rate (Per Second): 80M
- Number of Inputs: 2
- Input Type: Differential
- Data Interface: LVDS - Serial
- Configuration: S/H-ADC
- Ratio - S/H:ADC: 1:1
- Number of A/D Converters: 2
- Architecture: Pipelined
- Reference Type: Internal
- Voltage - Supply, Analog: 1.7V ~ 1.9V
- Voltage - Supply, Digital: 1.7V ~ 1.9V
- Features: Simultaneous Sampling
- Operating Temperature: -40°C ~ 85°C
- Package / Case: 32-WFQFN Exposed Pad, CSP
- Supplier Device Package: 32-LFCSP (5x5)
- Mounting Type: Surface Mount
- Base Part Number: AD9635
- detail: 12 Bit Analog to Digital Converter 2 Input 2 Pipelined 32-LFCSP (5x5)
