- دیتاشیت 30A Range Bidirectional Current Shunt Monitor
30A Range Bidirectional Current Shunt Monitor دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | 30A Range Bidirectional Current Shunt Monitor |
|---|---|
| حجم فایل | 626.782 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 15 |
دانلود دیتاشیت 30A Range Bidirectional Current Shunt Monitor |
دانلود دیتاشیت |
|---|
سایر مستندات
INA250-Q1 Datasheet 36 pages
INA250A1QPWRQ1 35 pages
مشخصات فنی
- RoHS: true
- Category: Operational Amplifier/Comparator/Current-Sensing Amplifiers
- Datasheet: Texas Instruments INA250A3QPWRQ1
- Supply Current: 200uA
- Number of Channels: 1
- Operating Temperature: -40°C~+125°C
- Package: TSSOP-16
- Manufacturer: Texas Instruments
- Series: Automotive, AEC-Q100
- Package / Case: 16-TSSOP (0.173", 4.40mm Width)
- Number of Circuits: 1
- Current - Supply: 200µA
- Voltage - Supply, Single/Dual (±): 2.7V ~ 36V
- Part Status: Active
- Slew Rate: 0.2V/µs
- Mounting Type: Surface Mount
- Gain Bandwidth Product: 50kHz
- Amplifier Type: Current Sense
- Packaging: Cut Tape (CT)
- Base Part Number: INA250
- Current - Input Bias: 28µA
- Output Type: -
- Supplier Device Package: 16-TSSOP
- detail: Current Sense Amplifier 1 Circuit 16-TSSOP
