ISO7041FDBQR دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت ISO7041FDBQR	دانلود دیتاشیت

RoHS: true
Category: Communication Interface Chip/UART/485/232/Digital Isolators
Data Rate: 2Mbps
Datasheet: Texas Instruments ISO7041FDBQR
Applications: SPI
Supply Voltage: 1.71V~1.89V;2.25V~5.5V
Forward Channel: 3
Reverse channel: 1
Number of Channels: 4
Isolation Technology: 电容隔离
Operating Temperature: -55°C~+125°C
Voltage Isolation or Not: Without voltage isolation
Package: SSOP-16-150mil-0.635mm
Manufacturer: Texas Instruments
Type: SPI
Pulse Width Distortion (Max): 10ns
Rise / Fall Time (Typ): 5ns, 5ns (Max)
Base Part Number: ISO704
Voltage - Isolation: 3000Vrms
Package / Case: 16-SSOP (0.154", 3.90mm Width)
Voltage - Supply: 2.25V ~ 3.6V
Supplier Device Package: 16-SSOP
Common Mode Transient Immunity (Min): 50kV/µs
Series: -
Technology: Capacitive Coupling
Channel Type: Unidirectional
Propagation Delay tpLH / tpHL (Max): 165ns, 165ns
Part Status: Active
Mounting Type: Surface Mount
Isolated Power: No
Inputs - Side 1/Side 2: 3/1
Packaging: Tape & Reel (TR)
detail: SPI Digital Isolator 3000Vrms 4 Channel 2Mbps 50kV/µs CMTI 16-SSOP (0.154", 3.90mm Width)
