دیتاشیت PIC18LF27K42-E/SP
مشخصات دیتاشیت
| نام دیتاشیت | PIC18(L)F26 to 57K42 Datasheet |
|---|---|
| حجم فایل | 11291.003 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 833 |
دانلود دیتاشیت PIC18(L)F26 to 57K42 Datasheet |
PIC18(L)F26 to 57K42 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- EEPROM: 1KB
- CPU Core: PIC
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- RAM Size: 8KB
- Watchdog: Yes
- ADC (Bit): 12bit
- DAC (Bit): 5bit
- Datasheet: Microchip Tech PIC18LF27K42-E/SP
- PWM (Bit): -
- Real-Time Clock: -
- CPU Maximum Speed: 64MHz
- GPIO Ports Number: 25
- Low-Voltage Detect: Yes
- CCP Capture/Compare: -
- Internal Comparator: -
- Internal Oscillator: Yes
- Peripheral/Function: PWM
- Program Memory Type: FLASH
- Direct Memory Access: Yes
- Program Storage Size: 128KB
- Universal Serial Bus: -
- communication protocol: -
- Operating Voltage Range: 1.8V~3.6V
- Infrared Data Association: -
- Operating Temperature Range: -40°C~+125°C
- Secure Digital Input and Output: -
- Package: SPDIP-28
- Manufacturer: Microchip Tech
- Series: PIC® XLP™ 18K
- Packaging: Tube
- Part Status: Active
- Core Processor: PIC
- Core Size: 8-Bit
- Speed: 64MHz
- Connectivity: I²C, LINbus, SPI, UART/USART
- Peripherals: Brown-out Detect/Reset, DMA, HLVD, POR, PWM, WDT
- Number of I/O: 25
- Program Memory Size: 128KB (64K x 16)
- EEPROM Size: 1K x 8
- Voltage - Supply (Vcc/Vdd): 1.8V ~ 3.6V
- Data Converters: A/D 24x12b; D/A 1x5b
- Oscillator Type: Internal
- Operating Temperature: -40°C ~ 125°C (TA)
- Mounting Type: Through Hole
- Package / Case: 28-DIP (0.300", 7.62mm)
- Supplier Device Package: 28-SPDIP
- Base Part Number: PIC18LF27K42
- detail: PIC PIC® XLP™ 18K Microcontroller IC 8-Bit 64MHz 128KB (64K x 16) FLASH 28-SPDIP
