دیتاشیت ADUM1410BRWZ-RL
مشخصات دیتاشیت
| نام دیتاشیت | ADUM1410-12 Datasheet |
|---|---|
| حجم فایل | 400.438 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 22 |
دانلود دیتاشیت ADUM1410-12 Datasheet |
ADUM1410-12 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Communication Interface Chip/UART/485/232/Digital Isolators
- Data Rate: 10Mbps
- Datasheet: Analog Devices ADUM1410BRWZ-RL
- Applications: -
- Supply Voltage: 2.7V~5.5V
- Forward Channel: 4
- Reverse channel: 0
- Number of Channels: 4
- Isolation Technology: Magnetic isolation
- Operating Temperature: -
- Voltage Isolation or Not: 带电压隔离
- Package: SOP-16-300mil
- Manufacturer: Analog Devices
- Series: iCoupler®
- Packaging: Cut Tape (CT)
- Part Status: Active
- Technology: Magnetic Coupling
- Type: General Purpose
- Isolated Power: No
- Inputs - Side 1/Side 2: 4/0
- Channel Type: Unidirectional
- Voltage - Isolation: 3750Vrms
- Common Mode Transient Immunity (Min): 25kV/µs
- Propagation Delay tpLH / tpHL (Max): 50ns, 50ns
- Pulse Width Distortion (Max): 5ns
- Rise / Fall Time (Typ): 2.5ns, 2.5ns
- Voltage - Supply: 2.7V ~ 5.5V
- Mounting Type: Surface Mount
- Package / Case: 16-SOIC (0.295", 7.50mm Width)
- Supplier Device Package: 16-SOIC
- Base Part Number: ADUM1410
- detail: General Purpose Digital Isolator 3750Vrms 4 Channel 10Mbps 25kV/µs CMTI 16-SOIC (0.295", 7.50mm Width)
