دیتاشیت ADG5436BRUZ-REEL7

مشخصات دیتاشیت

دانلود دیتاشیت ADG5436	ADG5436 Datasheet

RoHS: true
Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
Datasheet: Analog Devices ADG5436BRUZ-REEL7
Turn-on time: 213ns
Turn-off time: 152ns
Supply Voltage: 9V~40V
Switch Circuit: SPDT(SPDT)
Number of Channels: 2
On-State Resistance (Max): 10Ω
Package: TSSOP-16
Manufacturer: Analog Devices
Series: -
Packaging: Cut Tape (CT)
Part Status: Active
Multiplexer/Demultiplexer Circuit: 2:1
Number of Circuits: 2
Channel-to-Channel Matching (ΔRon): 350mOhm
Voltage - Supply, Single (V+): 9V ~ 40V
Voltage - Supply, Dual (V±): ±9V ~ 22V
Switch Time (Ton, Toff) (Max): 213ns, 152ns
-3db Bandwidth: 100MHz
Charge Injection: 250pC
Channel Capacitance (CS(off), CD(off)): 18pF, 63pF
Current - Leakage (IS(off)) (Max): 250pA
Crosstalk: -58dB @ 1MHz
Operating Temperature: -40°C ~ 125°C (TA)
Mounting Type: Surface Mount
Package / Case: 16-TSSOP (0.173", 4.40mm Width)
Supplier Device Package: 16-TSSOP
Base Part Number: ADG5436
detail: 2 Circuit IC Switch 2:1 10Ohm 16-TSSOP
