دیتاشیت ADP5071AREZ-R7
مشخصات دیتاشیت
| نام دیتاشیت |
ADP5071
|
| حجم فایل |
1033.991
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
27
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Converters
-
Function:
boost converterType;Buck-boost type
-
Topology:
Boost;SEPIC
-
Datasheet:
Analog Devices ADP5071AREZ-R7
-
Output Type:
Adjustable
-
Input Voltage:
2.85V~15V
-
Number of Outputs:
2
-
Switching Frequency:
1.2MHz;2.4MHz
-
Output Current (Max):
1.2A;2A
-
Operating Temperature:
-40°C~+125°C@(TJ)
-
Synchronous Rectification:
NO
-
Package:
TSSOP-20-EP
-
Manufacturer:
Analog Devices
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Output Configuration:
Positive and Negative (Dual Rail)
-
Voltage - Input (Min):
2.85V
-
Voltage - Input (Max):
15V
-
Voltage - Output (Min/Fixed):
0.8V, 1.6V
-
Voltage - Output (Max):
±39V
-
Current - Output:
1.2A, 2A
-
Frequency - Switching:
1.2MHz, 2.4MHz
-
Synchronous Rectifier:
No
-
Mounting Type:
Surface Mount
-
Package / Case:
20-TSSOP (0.173", 4.40mm Width) Exposed Pad
-
Supplier Device Package:
20-TSSOP-EP
-
Base Part Number:
ADP5071
-
detail:
Boost, SEPIC Switching Regulator IC Positive and Negative (Dual Rail) Adjustable 0.8V, 1.6V 2 Output 1.2A, 2A 20-TSSOP (0.173", 4.40mm Width) Exposed Pad
