دیتاشیت AD7734BRUZ-REEL7

AD7734

مشخصات دیتاشیت

نام دیتاشیت AD7734
حجم فایل 622.423 کیلوبایت
نوع فایل pdf
تعداد صفحات 32

دانلود دیتاشیت AD7734

AD7734 Datasheet

مشخصات

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
  • Datasheet: Analog Devices AD7734BRUZ-REEL7
  • Interface: SPI;DSP
  • resolution: 24Bit
  • Supply Voltage: 5V
  • number of channels: 4
  • sampling frequency: 15.4kHz
  • Operating Temperature: -40°C~+105°C
  • Package: TSSOP-28
  • Manufacturer: Analog Devices
  • Series: -
  • Packaging: Tube
  • Part Status: Obsolete
  • Number of Bits: 24
  • Sampling Rate (Per Second): 15.4k
  • Number of Inputs: 4
  • Input Type: Single Ended
  • Data Interface: SPI, DSP
  • Configuration: MUX-ADC
  • Ratio - S/H:ADC: -
  • Number of A/D Converters: 1
  • Architecture: Sigma-Delta
  • Reference Type: External
  • Voltage - Supply, Analog: 5V
  • Voltage - Supply, Digital: 2.7V ~ 3.6V, 5V
  • Features: True Bipolar
  • Package / Case: 28-TSSOP (0.173", 4.40mm Width)
  • Supplier Device Package: 28-TSSOP
  • Mounting Type: Surface Mount
  • Base Part Number: AD7734
  • detail: 24 Bit Analog to Digital Converter 4 Input 1 Sigma-Delta 28-TSSOP
