- دیتاشیت AD9284BCPZ-250
دیتاشیت AD9284BCPZ-250
مشخصات دیتاشیت
| نام دیتاشیت | AD9284BCPZ-250 |
|---|---|
| حجم فایل | 89.358 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 24 |
AD9284BCPZ-250 |
دانلود دیتاشیت |
|---|
سایر مستندات
AD9284 24 pages
AD9284BCPZ-250 25 pages
مشخصات فنی
- RoHS: true
- Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
- Datasheet: Analog Devices AD9284BCPZ-250
- Package: LFCSP-48
- Manufacturer: Analog Devices
- Series: -
- Packaging: Tray
- Part Status: Active
- Number of Bits: 8
- Sampling Rate (Per Second): 250M
- Number of Inputs: 2
- Input Type: Differential, Single Ended
- Data Interface: LVDS - Parallel
- Configuration: S/H-ADC
- Ratio - S/H:ADC: 1:1
- Number of A/D Converters: 2
- Architecture: Pipelined
- Reference Type: Internal
- Voltage - Supply, Analog: 1.7V ~ 1.9V
- Voltage - Supply, Digital: 1.7V ~ 1.9V
- Features: Simultaneous Sampling
- Operating Temperature: -40°C ~ 85°C
- Package / Case: 48-VFQFN Exposed Pad, CSP
- Supplier Device Package: 48-LFCSP-VQ (7x7)
- Mounting Type: Surface Mount
- Base Part Number: AD9284
- detail: 8 Bit Analog to Digital Converter 2 Input 2 Pipelined 48-LFCSP-VQ (7x7)
