دیتاشیت AD9649BCPZ-20
مشخصات دیتاشیت
| نام دیتاشیت |
AD9649
|
| حجم فایل |
1115
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
32
|
مشخصات
-
RoHS:
true
-
Category:
ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
-
Datasheet:
Analog Devices AD9649BCPZ-20
-
Interface:
Parallel
-
resolution:
14Bit
-
Supply Voltage:
1.7V~1.9V
-
differential input:
Yes
-
number of channels:
1
-
sampling frequency:
20MHz
-
Operating Temperature:
-40°C~+85°C
-
Package:
LPCSP-32
-
Manufacturer:
Analog Devices
-
Series:
-
-
Packaging:
Tray
-
Part Status:
Active
-
Number of Bits:
14
-
Sampling Rate (Per Second):
20M
-
Number of Inputs:
1
-
Input Type:
Differential, Single Ended
-
Data Interface:
Parallel
-
Configuration:
S/H-ADC
-
Ratio - S/H:ADC:
1:1
-
Number of A/D Converters:
1
-
Architecture:
Pipelined
-
Reference Type:
External, Internal
-
Voltage - Supply, Analog:
1.7V ~ 1.9V
-
Voltage - Supply, Digital:
1.7V ~ 1.9V
-
Features:
-
-
Package / Case:
32-VFQFN Exposed Pad, CSP
-
Supplier Device Package:
32-LFCSP-VQ (5x5)
-
Mounting Type:
Surface Mount
-
Base Part Number:
AD9649
-
detail:
14 Bit Analog to Digital Converter 1 Input 1 Pipelined 32-LFCSP-VQ (5x5)
