SN74ALVCH16821DGGR دیتاشیت

مشخصات دیتاشیت

دانلود دیتاشیت SN74ALVCH16821DGGR	دانلود دیتاشیت

RoHS: true
Category: Logic ICs/Flip Flops
Datasheet: Texas Instruments SN74ALVCH16821DGGR
Package: TSSOP-56-6.1mm
Manufacturer: Texas Instruments
Series: 74ALVCH
Type: D-Type
Package / Case: 56-TFSOP (0.240", 6.10mm Width)
Current - Output High, Low: 24mA, 24mA
Number of Elements: 2
Function: Standard
Clock Frequency: 150MHz
Current - Quiescent (Iq): 40µA
Part Status: Active
Number of Bits per Element: 10
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 85°C (TA)
Max Propagation Delay @ V, Max CL: 4.5ns @ 3.3V, 50pF
Input Capacitance: 3.5pF
Voltage - Supply: 1.65V ~ 3.6V
Packaging: Cut Tape (CT)
Base Part Number: SN74ALVCH
Supplier Device Package: 56-TSSOP
Output Type: Tri-State, Non-Inverted
Trigger Type: Positive Edge
detail: Flip Flop 2 Element D-Type 10 Bit Positive Edge 56-TFSOP (0.240", 6.10mm Width)
