دیتاشیت AD7984BCPZ-RL7

AD7984

مشخصات دیتاشیت

نام دیتاشیت AD7984
حجم فایل 601.083 کیلوبایت
نوع فایل pdf
تعداد صفحات 24

دانلود دیتاشیت AD7984

AD7984 Datasheet

مشخصات

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
  • Datasheet: Analog Devices AD7984BCPZ-RL7
  • Interface: SPI;DSP
  • resolution: 18Bit
  • Supply Voltage: 2.375V~2.625V
  • differential input: Yes
  • number of channels: 1
  • sampling frequency: 1.33MHz
  • Operating Temperature: -40°C~+85°C
  • Package: LFCSP-10
  • Manufacturer: Analog Devices
  • Series: PulSAR®
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Number of Bits: 18
  • Sampling Rate (Per Second): 1.33M
  • Number of Inputs: 1
  • Input Type: Differential
  • Data Interface: SPI, DSP
  • Configuration: S/H-ADC
  • Ratio - S/H:ADC: 1:1
  • Number of A/D Converters: 1
  • Architecture: SAR
  • Reference Type: External
  • Voltage - Supply, Analog: 2.375V ~ 2.625V
  • Voltage - Supply, Digital: 2.375V ~ 2.625V
  • Features: -
  • Package / Case: 10-VFDFN Exposed Pad, CSP
  • Supplier Device Package: 10-LFCSP-WD (3x3)
  • Mounting Type: Surface Mount
  • Base Part Number: AD7984
  • detail: 18 Bit Analog to Digital Converter 1 Input 1 SAR 10-LFCSP-WD (3x3)
