دیتاشیت AD5542CRZ-REEL7

AD5541,42

مشخصات دیتاشیت

نام دیتاشیت AD5541,42
حجم فایل 384.779 کیلوبایت
نوع فایل pdf
تعداد صفحات 20

دانلود دیتاشیت AD5541,42

AD5541,42 Datasheet

مشخصات

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Digital To Analog Converters (DACs)
  • Datasheet: Analog Devices AD5542CRZ-REEL7
  • Interface: SPI;DSP
  • Resolution: 16Bit
  • Output Type: Voltage-非缓冲
  • Settling Time: 1us
  • Supply Voltage: 2.7V~5.5V
  • Integral nonlinearity: ±0.5LSB
  • Operating Temperature: -40°C~+85°C
  • Package: SOP-14
  • Manufacturer: Analog Devices
  • Series: -
  • Packaging: Tube
  • Part Status: Obsolete
  • Number of Bits: 16
  • Number of D/A Converters: 1
  • Differential Output: No
  • Data Interface: SPI, DSP
  • Reference Type: External
  • Voltage - Supply, Analog: 2.7V ~ 5.5V
  • Voltage - Supply, Digital: 2.7V ~ 5.5V
  • INL/DNL (LSB): ±0.5, ±0.5
  • Architecture: R-2R
  • Package / Case: 14-SOIC (0.154", 3.90mm Width)
  • Supplier Device Package: 14-SOIC
  • Mounting Type: Surface Mount
  • Base Part Number: AD5542
  • detail: 16 Bit Digital to Analog Converter 1 14-SOIC
