دیتاشیت ATSAMA5D41B-CUR
مشخصات دیتاشیت
نام دیتاشیت | ATSAMA5D4x Series Flyer |
---|---|
حجم فایل | 508.808 کیلوبایت |
نوع فایل | |
تعداد صفحات | 2 |
دانلود دیتاشیت ATSAMA5D4x Series Flyer |
ATSAMA5D4x Series Flyer Datasheet |
---|
مشخصات
- RoHS: true
- CPU Core: ARM-ASeries
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- Datasheet: Microchip Tech ATSAMA5D41B-CUR
- LCD Module: Yes
- CPU Maximum Speed: 600MHz
- Peripheral/Function: TRNG;硬件加密
- Universal Serial Bus: Yes
- Operating Temperature Range: -40°C~+85°C
- Secure Digital Input and Output: -
- Package: LFBGA-289
- Manufacturer: Microchip Tech
- Series: SAMA5D4
- Packaging: Cut Tape (CT)
- Part Status: Active
- Core Processor: ARM® Cortex®-A5
- Number of Cores/Bus Width: 1 Core, 32-Bit
- Speed: 600MHz
- Co-Processors/DSP: Multimedia; NEON™ SIMD
- RAM Controllers: LPDDR, LPDDR2, DDR2
- Graphics Acceleration: Yes
- Display & Interface Controllers: LCD, Touchscreen
- Ethernet: 10/100Mbps (1)
- SATA: -
- USB: USB 2.0 (3)
- Voltage - I/O: 1.2V, 1.8V, 3.3V
- Operating Temperature: -40°C ~ 85°C (TA)
- Security Features: AES, SHA, TDES, TRNG
- Package / Case: 289-LFBGA
- Supplier Device Package: 289-LFBGA (14x14)
- Additional Interfaces: EBI, I²C, MMC/SD/SDIO, SPI, SSC, UART, USART
- Base Part Number: ATSAMA5D41
- detail: ARM® Cortex®-A5 Microprocessor IC SAMA5D4 1 Core, 32-Bit 600MHz 289-LFBGA (14x14)
