AD9689BBPZ-2000 Datasheet
Datasheet specifications
| Datasheet's name | AD9689 |
|---|---|
| File size | 3114.877 KB |
| File type | |
| Number of pages | 134 |
Download Datasheet AD9689 |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Manufacturer: Analog Devices Inc.
- Series: -
- Packaging: Tray
- Part Status: Active
- Number of Bits: 14
- Sampling Rate (Per Second): 2G
- Number of Inputs: 2
- Input Type: Differential
- Data Interface: JESD204B
- Configuration: S/H-ADC
- Ratio - S/H:ADC: 1:1
- Number of A/D Converters: 2
- Architecture: Pipelined
- Reference Type: External, Internal
- Voltage - Supply, Analog: 0.95V ~ 1V, 1.85V ~ 1.95V, 2.44V ~ 2.56V
- Voltage - Supply, Digital: 0.95V ~ 1V, 1.85V ~ 1.95V
- Operating Temperature: -40°C ~ 85°C
- Package / Case: 196-LFBGA Exposed Pad
- Supplier Device Package: 196-BGA-ED (12x12)
- Mounting Type: Surface Mount
- Base Part Number: AD9689
- detail: 14 Bit Analog to Digital Converter 2 Input 2 Pipelined 196-BGA-ED (12x12)
