AD7506KNZ دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
AD7506KNZ
|
|
حجم فایل
|
100.961
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
4
|
مشخصات فنی
-
RoHS:
true
-
Category:
Logic ICs/Signal Switches / Encoders & Decoders / Multiplexers
-
Datasheet:
Analog Devices AD7506KNZ
-
Package:
PDIP-28
-
Manufacturer:
Analog Devices
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Obsolete
-
Switch Circuit:
-
-
Multiplexer/Demultiplexer Circuit:
16:1
-
Number of Circuits:
1
-
On-State Resistance (Max):
450Ohm
-
Channel-to-Channel Matching (ΔRon):
18Ohm
-
Voltage - Supply, Single (V+):
-
-
Voltage - Supply, Dual (V±):
±15V
-
Switch Time (Ton, Toff) (Max):
1.5µs, 1µs
-
-3db Bandwidth:
-
-
Charge Injection:
-
-
Channel Capacitance (CS(off), CD(off)):
5pF, 40pF
-
Current - Leakage (IS(off)) (Max):
5nA
-
Crosstalk:
-
-
Operating Temperature:
0°C ~ 70°C (TA)
-
Mounting Type:
Through Hole
-
Package / Case:
28-DIP (0.600", 15.24mm)
-
Supplier Device Package:
28-PDIP
-
Base Part Number:
AD7506
-
detail:
1 Circuit IC Switch 16:1 450Ohm 28-PDIP
