دیتاشیت UCC2808AQDR-2EP

مشخصات دیتاشیت

دانلود دیتاشیت UCC2808A-1EP/2EP	UCC2808A-1EP/2EP Datasheet

RoHS: true
Category: Power Supply Chip/DC-DC Controllers
Function: Buck-boost type
Topology: Push-pull
Datasheet: Texas Instruments UCC2808AQDR-2EP
Input Voltage: 4.1V~15V
Duty Cycle (Max): 49%
Number of Outputs: 2
Switching Frequency: 194kHz
Operating Temperature: -40°C~+125°C@(TJ)
Synchronous Rectification: NO
Package: SOP-8
Manufacturer: Texas Instruments
Voltage - Supply (Vcc/Vdd): 4.1V ~ 15V
Base Part Number: UCC280
Package / Case: 8-SOIC (0.154", 3.90mm Width)
Output Configuration: Positive
Series: -
Supplier Device Package: 8-SOIC
Frequency - Switching: 194kHz
Part Status: Active
Mounting Type: Surface Mount
Control Features: Frequency Control
Clock Sync: No
Serial Interfaces: -
Packaging: Cut Tape (CT)
Synchronous Rectifier: No
Output Type: Transistor Driver
Output Phases: 1
detail: Push-Pull Regulator Positive Output Step-Up/Step-Down DC-DC Controller IC 8-SOIC
